Corrosion Resistant PPR Pipes And Fittings 20mm-160mm Plastic Plumbing Tubing

Basic Information
Place of Origin: Sichuan, China
Brand Name: YOUYUE
Certification: ISO 9001
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Standard package or customized packing
Delivery Time: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 1000000 Meters per Month
Detail Information
Specification: De20 - De110mm Color: Grey, White
Life Span: More Than 50 Years Material: PPR
Name: PP-R Hot&cold Water Pipe And Accessories Length: 4m / 5.8m / As Customer's Request
Usage: Water Pipe Size: Customized Size
High Light:

Corrosion Resistant PPR Pipes And Fittings

,

20mm PPR Pipes And Fittings

,

160mm Plastic Plumbing Tubing


Product Description

Corrosion Resistant Cold Water And Hot Water Ppr Pipes And Fittings



PPR pipes and fittings is a new type of environment-friendly cold/hot water supply product widely used in developed countries. As the raw material, polypropylene is a high molecular weight hydrocarbon that is insoluble in water, and has biological inertia and no damage to groundwater and soil. The pipeline system consists of pipes and fittings connected by the same material heat fusion technique, which has no impact on its overall strength and makes sure there is no leakage, eliminating the hidden danger of water leakage.



About the product

PPR pipes and fittings are formed via extrusion and plastic injection using the main raw material of polypropylene resin.

Its quality is assured, and meets and even surpasses the relative requirements of the state. Polypropylene resin (PP-R) belongs to polyolefin, and is a kind of high-molecular-weight hydrocarbons. PP-R does not dissolve in water and has biological inertia. It does not have any damage to the underground water or soil and its sanitary is reliable. The product conforms to the sanitary and environment standards in the whole process from its production and application to its disposal and recycling.





Features of PPR pipes and fittings



Sanitary performance is reliable: NOn-toxic and has no chemical effective, no metal additives and no bacteria produced. It could effectively prevent secondary pollution of drinking water.

Fine physical performance: Anti-impact, anti-hydro-pressure and fine airproof performance.

Erosion-resistance and no scaling: The product can resist several chemical medium so as to avoid pipes being blocked by scaling.

Applicable fields: It could be inserted in the wall, paved in the ground or set up visibly in the construction.

Anti-aging and long life span: The product could have a lifespan of over 50 years when used under normal conditions, thus significantly lowering the expenses generated in maintenance and replacement.

Of light materials:The product is easy to load, unload and transport; also, its configuration is easy and reliable; meanwhile the installation period is shortened to effectively lower the expenses generated in installation and maintenance.



Application of PPR pipes and fittings:



Hot and cold water supply systems of residential, commercial and office buildings.

Direct drinking water and water supply systems.

Pipe work for the transportation of erosive mediums such as those in the chemical and pharmaceutical industries.

Sanitary pipe work for food, beverage and pharmaceutical industries. Pipe work for ventilation, central air-conditioning system and home air- conditioning system.

Heating system including floor, wainscot and radiation heating systems.



Product series

Specification:20mm〜 160mm

Pipe series: S5,S4,S3.2,S2.5

Product color: White and gray

Product types: In full range with accessories



Standard applied:



GB/T18742.1-2002. GB/T18742.2-2002. GB/T18472.3-2002 Adopted international standard: ISO/DIS15874.2:1999

Sanitary performance: Standard for safety evaluation of equipment and protective materials in drinking water system





Quick Details



place of Origin: Sichuan, China
Life span: more than 50 years
Material: HDPE
Pipe series: S5,S4,S3.2,S2.5
Specification: DN20~DN160mm
Length: accordingly
Thickness: accordingly
Processing Service: moulding, Cutting
Name: HDPE water pipe
Color: grey&white
Usage: water supply





Supply Ability

Supply Ability 999999 Meter/Meters per Month



Packaging & Delivery

Packaging Details upon request

Port Chongqing , Chengdu , Shanghai, any main port in China



Lead Time:

Quantity(Meters) 1 - 5000 5001 - 10000 >10000
Est. Time(days) 15 20 To be negotiated





OEM &ODM Support
MOQ 1Pcs as samples 100 Pcs for formal order
Standard: CE, ISO9001,ISO14001:2004 SIZE :
Pressure grade: PN 12.5-25MPa T20*1/2"F
Temperature: -40 ~ +95°C T25*1/2"F
Colors: White or customized T25*3/4"F
Connection: Welding T32*3/4"F
Free sample: Support T32*1"F
Warranty: More than 50 years
Application: Hot and cold water
standard standard
